GPT-9000 Series Quick Start Guide
10
Set the Test Voltage/Current (MANU mode only)
 Use the UP/DOWN arrow keys to bring the cursor to
the Test voltage/Current.
 Use the scroll wheel to set the voltage/current.
Choose HI/LO SET limits (MANU mode only)
 Press the HI/LO soft-key or use the UP/DOWN
arrow keys to choose either HI or LO SET.
 Use the scroll wheel to edit the setting.
I / LH O
OR
Ramp Time (MANU mode only)
 Use the UP/DOWN arrow keys to bring the cursor to
Ramp time.
 Use the scroll wheel to set the ramp time.
 ACW, DCW and IR only
Test Time (MANU mode only)
 Press the TIMER soft-key or use the UP/DOWN
arrow keys to select TIMER.
 Use the scroll wheel to set the test time.
I M ET R
OR
