Reference (MANU mode only)
Use the UP/DOWN arrow keys to bring the cursor to
REF#.
Use the scroll wheel to set the reference.
For GB tests, the ZERO function can be used to
automatically set a reference offset to compensate for
the resistance of the test leads (see page 13).
Frequency (ACW, GB/MANU mode only)
Use the UP/DOWN arrow keys to bring the cursor to
FREQ.
Use the scroll wheel to set the test frequency (ACW
and GB mode only).
Set the AUTO or MANU Test Name
Use the UP/DOWN arrow keys to bring the cursor to
MANU_NAME or AUTO_NAME.
Use the scroll wheel to select a character.
Press the LEFT or RIGHT arrow keys to go to the
next/previous character.
Continue to enter characters until the test name is
entered.
The test name will be saved when MANU/AUTO is
saved.
Save MANU/AUTO and Return to VIEW Status
Press the EDIT/SAVE key. The current test is saved
in memory.
The tester reverts back to VIEW status.
Exit the EDIT Status and Return to VIEW Status
Press the ESC key.
The tester does not save and returns back to VIEW
status.
