Pulse Width
20nS~999.7ks(limited by the
current frequency setting)
Variable duty Cycle
0.1%~99.9%(limited by the current
frequency setting)
Leading and Trailing Edge
Time(5)
10nS~20S(1ns resolution) (limited
by the current frequency and pulse
width settings)
Overshoot
<5%
Jitter
100ppm+500ps(4)
RF Generator
Arbitrary
Functions
ARB function
Built-in
Sample Rate
200 MSa/s
Repetition Rate
100MHz
Waveform Length
16k points
Amplitude Resolution
14 bits
User-defined output section
From point 2~16384 (optional)
Jitter
20ppm+5ns
Frequency
Characteristics
Range
Sine MFG-2XXXMF
1uHz~160MHz (DDS)
1uHz~60MHz (ARB)
(MFG-2XXXMR)
1uHz~320MHz (DDS)
1uHz~60MHz (ARB)
Square 25MHz(max)
Triangle, Ramp 1MHz
Resolutio
1μHz
Accuracy Stability
±20 ppm
Aging
±1 ppm, per 1 year
Tolerance
≤1μHz
Output
Characteristics(2)
Amplitude(into 50Ω)
1mVpp to 2 Vpp
(MFG-2XXXMF)
1mVpp to 1 Vpp
(MFG-2XXXMR)
Accuracy
±2% of setting ±1 mVpp
(at 1 kHz/into 50Ω without DC
