GW Instek MFG-2000 Series Quick Start Guide

MFG-2000 Quick Start Guide
78
offset))
Resolution
1mV or 3 digits
Flatness
± 1% (0.1dB) ≦1MHz
± 3% (0.3dB) ≦50 MHz
± 10% (0.9dB) ≦160MHz
± 35% (3.5dB) ≦320MHz
(sinewave relative to 1 kHz/into
50Ω)
Offset
±1 Vpk ac +dc (into 50Ω)
±2Vpk ac +dc (Open circuit)
Waveform
Output
Impedance
50Ω typical (fixed)
>10MΩ (output disabled)
Sine wave
Characteristics(3)
Harmonic
Distortion(sine,1vpp,50Ω )
–60 dBc <200kHz
–55 dBc 200kHz～1 MHz
–45 dBc 1MHz～10 MHz
–30 dBc 10MHz～320MHz
Total harmonic distortion
< 0.1% (Ampl>1Vpp)
DC~100 kHz
Square wave
Characteristics
Rise/Fall Time
<15ns
Overshoot
<5%
Asymmetry
1% of period +5 ns
Variable duty Cycle
0.01% to 99.99%(limited by the
current frequency setting)
Jitter
20ppm+500ps(4)
Ramp
Characteristics
Linearity
< 0.1% of peak output
Variable Symmetry
0% to 100%
Modulation/
Sweep
Modulation Type
AM,ASK,FM,FSK,PM,PSK,PWM
(The detail same as CH1
modulation specification)
Sweep type
Frequency
Source
INT/EXT（INT only for
AM,FM,PM, PWM)
Modulating Frequency
Sine-DDS 5us~327.68mS
