GW Instek MFG-2000 Series Quick Start Guide

QUICK REFERENCE
79
(Resolution:5uS)
Sine-ARB 2mHz to20kHz
(Resolution:1mHz)
PSK
Carrier Waveforms
Sine-DDS
Modulating Waveforms
50% duty cycle square
Internal Frequency
2mHz to 1 MHz
Phase Range
0°~360.0°
Source
Internal / External
ASK
Carrier Waveforms
Sine-DDS
Modulating Waveforms
50% duty cycle square
Internal Frequency
2mHz to 1 MHz
Amplitude Range
0%~100.0%
Source
Internal / External
Power
Amplifier
Input Impedance
10KΩ
Input voltage
1.25Vpmax
Working Mode
Constant Voltage
Gain
20dB
Output Power
（RL=8Ω）
20W(Square）
Output Voltage
12.5Vpmax
Output Current
1.6Amax
Rise/Fall Time
<2.5uS
FullPower Bandwidth
DC-100KHz
Overshoot
5%
Total harmonic distortion
< 0.1% (Ampl>1Vpp)
20Hz~20 kHz
Ground Isolation
42Vpk max
Advanced
Functions
AM Modulation
Carrier Waveforms
Sine, Square, Triangle, Ramp,
Pulse,Arb
Modulating Waveforms
Sine, Square, Triangle,Upramp,
Dnramp
Modulating Frequency
2mHz to 20kHz (Int)DC to
