GW Instek MFG-2000 Series Quick Start Guide

MFG-2000 Quick Start Guide
80
20kHz (Ext)
Depth
0% to 120.0%
Source
Internal / External
FM Modulation
Carrier Waveforms
Sine, Square, Triangle, Ramp
Modulating Waveforms
Sine, Square, Triangle,Upramp,
Dnramp
Modulating Frequency
2mHz to20kHz (Int)DC to
20kHz (Ext)
Peak Deviation
DC to max frequency
Source
Internal / External
PM Modulation
Carrier Waveforms
Sine, Square, Triangle, Ramp
Modulating
Waveforms
Sine, Square, Triangle,
Upramp, Dnramp
Modulation Frequency
2mHz to20kHz (Int)DC to
20kHz (Ext)
Phase deviation
0°~360.0°
Source
Internal / External
SUM
Modulation
Carrier Waveforms
Sine, Square, Triangle, Ramp
Modulating
Waveforms
Sine, Square, Triangle,
Upramp, Dnramp
Modulation Frequency
2mHz to20kHz (Int)DC to
20kHz (Ext)
SUM depth
0%~100.0%
Source
Internal / External
PWM
Modulation
Carrier Waveforms
Sine, Square, Triangle, Ramp
Modulating
Waveforms
Sine, Square, Triangle,
Upramp, Dnramp
Modulation Frequency
2mHz to20kHz (Int)DC to
20kHz (Ext)
Phase deviation
0%~100.0% pulse width
Source
Internal / External
FSK
Carrier Waveforms
Sine, Square, Triangle,
Ramp,Pulse
