Modulating Waveforms
50% duty cycle square
Internal Frequency
2mHz to 1 MHz
Frequency Range
1μHz to max frequency
Source
Internal / External
Sweep
Waveforms
Sine, Square, Triangle, Ramp
Type
Linear or Logarithmic
Sweep direction
Sweep up or sweep down
Start/Stop Freq
1uHz to max frquency
Sweep Time
1ms to 500s
Source
Internal / External
Trigger
Single, External, Internal.
Marker
Marker signal on falling
edge(programmable)
Source
Internal / External
Burst
Waveforms
Sine, Square, Triangle, Ramp
Frequency
Max Frequency 25MHz
Pulse count
1~1000000 Cycles or intfinite
Start/ Stop Phase
-360.0°~+360.0°
Internal Frequency
1 us~500 s
Gate source
External Trigger
Trigger Source
Single, External, Internal.
Trigger Delay
NCycle, Infinite
0s~100 s
External Trigger
Input
Type
For FSK, Burst, Sweep
Input Level
TTL Compatibility
Slope
Rising or Falling(Selectable)
Pulse Width
>100ns
Input Impedance
10kΩ，DC coupled
External
Modulation
Input
Type
For AM,FM, PM,SUM,PWM
Voltage Range
±5V full scale
Input Impedance
10kΩ
Frequency
DC to 20kHz
Ground Isolation
42Vpk max
