GW Instek MFG-2120MA User Manual

MODULATION
167
SUM Carrier Waveform
Background
The SUM carrier waveform is a sinewave by
default.
Panel Operation
1. Press the Waveform key.

2. Press F1~F5 to select the
carrier waveform.


~


Range
Carrier Waveform
Sine, square, pulse, ramp
and noise wave.
SUM Carrier Frequency
The maximum carrier frequency depends on the selected carrier
waveform. The default carrier frequency is 1kHz.
Panel Operation
1. Press the FREQ/Rate key to
select the carrier frequency.
Q
2. The FREQ parameter will become highlighted
in the parameter window.
3. Use the arrow keys and scroll
wheel or number pad to enter
the frequency.

/


 



4. Press F2 ~ F6 to select the
frequency units.
z

~
z
Range
Carrier Waveform
Carrier Frequency
Sine wave
1μHz~60MH(max)
Square wave
1μHz~25MHz(max)

GW Instek MFG-2120MA Specifications

General

Model	MFG-2120MA
Category	Inverter
Output Impedance	50 Ω
Waveform Types	Sine, Square
Modulation Types	AM, FM, PWM, FSK
Power Supply	AC 100V ~ 240V ±10%, 50/60Hz
Harmonic Distortion	< 0.5%
