GW Instek MFG-2120MA User Manual

REMOTE INTERFACE
287
SOURce[1|2|3|3RF]:PULSe:WIDTh
Source Specific
Command
Description
Sets or queries the pulse width. The default pulse
width is 50us.
Pulse width is defined as the time from the rising
to falling edges (at a threshold of 50%).
Note
The pulse width is restricted to the following
limitations:
Pulse Width ≥ Minimum Pulse Width
Pulse Width < Pulse Period - Minimum Pulse
Width
Syntax
SOURCEPULSE:PULSe:WIDTh
{<seconds>|MINimum|MAXimum}
Example
SOURCEPULSE:PULS:WIDT MAX
Sets the pulse width to the maximum allowed.
Query Syntax
SOURCEPULSE:PULSe:WIDTh?
[MINimum|MAXimum]
Return Parameter
<seconds>
≧20 ns (limited by the
current frequency setting)
Example
SOURCEPULSE:PULS:WIDT?
+2.000000000000E-08
The pulse width is set to 20 nanoseconds.
OUTPut
Source Specific
Command
Description
Enables/Disables or queries the front panel
output. The default is set to off.
Note
If the output is overloaded by an external voltage,
the output will turn off and an error message will
be displayed. The overload must first be removed
before the output can be turned on again with
output command.
