5-16
0. Return to boot menu
Enter your choice(0-3):
5) Configure the switch to load the Boot ROM file through FTP
In the protocol parameter setting menu, enter 2 to update the Boot ROM file using FTP, and then set the
FTP parameters.
Load File Name :update.bin
Server IP Address :10.10.10.2
Local IP Address :10.10.10.3
Gateway IP Address :0.0.0.0
FTP User Name :5120
FTP User Password :123
The parameters are described in Table 5-5.
Table 5-5 Description of the FTP parameters
Item Description
Load File Name : Name of the file to be downloaded
Server IP Address : IP address of the PC
Local IP Address : IP address of the switch
Gateway IP Address : IP address of the gateway
FTP User Name
Username for logging in to the FTP server, which should be consistent
with that configured on the FTP server.
FTP User Password
Password for logging in to the FTP server, which should be consistent
with that configured on the FTP server.
z Enter the file name and IP addresses based on the actual condition.
z If the switch and the server are on the same network segment, you can specify any unused IP
address of the network for the switch without specifying the gateway’s IP address; if they are not on
the same segment, you need to specify the gateway’s IP address so that the switch can
communicate with the server.
6) Update the Boot ROM file on the switch
Enter the corresponding parameters based on the actual condition. The system displays the following
information:
Will you Update Basic BootRom? (Y/N):Y
The system asks you whether you want to update the basic Boot ROM section. Click Y. The system
displays the following information after the update is complete:
Updating Basic BootRom...........Done!
Updating extended BootRom? (Y/N):Y
The system asks you whether you want to update the extended Boot ROM section. Click Y and then the
system displays the following information after the update is complete:
