3 Installing a Switch
On a mounting screw of the chassis of the H3C series switches, there is a seal labeled. You need to
keep it intact before asking the agent to maintain the switch. You need to get the permission of the local
agent before you can open the chassis. Otherwise, you will be responsible for irreversible damages
caused by your operations.
Installing the Switch into a 19-Inch Rack Using Mounting Brackets
The S5120-SI series is shipped with a pair of mounting brackets to fix and support the switch. Figure 3-1
shows how to install a S5120-SI series into a 19-inch rack.
Figure 3-1 Install a S5120-SI series into a 19-inch rack
Introduction to Mounting Brackets
Table 3-1 Mounting brackets for the S5120-SI series
Model Mounting bracket Description
S5120-20P-SI
S5120-28P-SI
Two-holed mounting
brackets (standard)
Figure 3-2 shows the appearance.
S5120-52P-SI
Four-holed mounting
brackets (standard)
Figure 3-3 shows the appearance.
