3-2
Figure 3-2 Two-holed mounting bracket
(1) Screw hole used to fix the mounting bracket to the rack (with an M6 screw)
(2) Screw hole used to fix the switch to the mounting bracket
Figure 3-3 Four-holed mounting bracket
(1) Screw hole used to fix the mounting bracket to the rack (with an M6 screw)
(2) Screw hole used to fix the switch to the mounting bracket
Attaching the Mounting Brackets to a Switch
The installation of actual mounting brackets varies with devices.
