H3C S5560X-HI Series User Manual

FRU
model
S6520X-30QC-EI
S6520X-30QC-HI
S6520X-54QC-EI
S6520X-54QC-HI
S6520X-30HC-EI
S6520X-30HC-HI
S6520X-54HC-EI
S6520X-54HC-HI
S6520X-30HF-EI
S6520X-54HF-EI
S6520X-30HF-HI
S6520X-54HF-HI
8
LSWM2XM
GT8P
Supported Supported Not supported
LSWM2MG
T8P
Supported Supported Not supported
LSWM2ZSP
2P
Supported Supported Not supported
LSWM2SP2
PB
Supported Supported Not supported
LSWM2SP4
PB
Supported Supported Not supported
Removable power supplies
The switch uses removable power supplies and supports the PSR250-12A, PSR250-12A1,
PSR450-12D, PSR180-12A-F, and PSR180-12A-B power supplies.
You can install one power supply, or two power supplies in 1+1 redundancy for the switch.
Table3-2 Power supplies available for the switch
Power supply
model
AC or DC
input
Specifications Reference
PSR250-12A
PSR250-12A1
AC input
• Rated input voltage range: 100 to
240 VAC @ 50/60 Hz
• Max input voltage range: 90 to 264
VAC @ 47 to 63 Hz
• Max output power: 250 W
H3C PSR250-12A &
PSR250-12A1 Power
Modules User Manual
High-voltage
DC input
• Rated input voltage range: 240
VDC
• Max input voltage range: 180 to
320 VDC
• Max output power: 250 W
PSR450-12D DC input
• Rated input voltage range: –48 to –
60 VDC
• Max input voltage range: –36 to –
72 VDC
• Max output power: 450 W
H3C PSR450 Power Supply
Series User Guide
PSR180-12A-F AC input
• Rated input voltage range: 100 to
240 VAC @ 56/60 Hz
• Max input voltage range: 90 to 264
VAC @ 47 to 63 Hz
• Max output power: 180 W
• Melting current of power supply
fuse: 6.3 A/250 V
H3C PSR180-12A &
PSR180-12D Power Supply
Series User Manual
PSR180-12A-B AC input
•
Rated input voltage range: 100 to
H3C PSR180-12A &
