4 Ports and LEDs
Ports
Console port
Table4-1 Console port specifications
Item Serial console port Micro USB console port
Connector type RJ-45 Micro USB Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII
terminal.
• Provides connection to the serial port
of a local PC running terminal
emulation program.
Provides connection to the USB port
of a local PC running terminal
emulation program.
Compatible devices All device models.
• S6520X-30QC-EI
• S6520X-54QC-EI
• S6520X-30HC-EI
• S6520X-54HC-EI
• S6520X-30QC-HI
• S6520X-54QC-HI
• S6520X-30HC-HI
• S6520X-54HC-HI
You cannot use both console ports at the same time. Only the Micro USB console port works when you
connect both ports.
Management Ethernet port
You can connect the management Ethernet port to a PC or management station for loading and
debugging software or remote management.
Table4-2 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Port transmission rate
• 10/100 Mbps, half/full duplex, MDI/MDI-X autosensing
• 1000 Mbps, full duplex, MDI/MDI-X autosensing
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
Compatible devices All device models
