IMPORTANT:
T
he SFP-GE-LX-SM1310-BIDI and SFP-GE-LX-SM1490-BIDI transceiver modules, the
SFP
-GE-LH40-SM1310-BIDI and SFP-GE-LH40-SM1550-BIDI transceiver modules, and the
SFP
-GE-LH70-SM1490-BIDI and SFP-GE-LH70-SM1550-BIDI transceiver modules must be used
in pairs. For example, if one end uses the
SFP-GE-LX-SM1310-BIDI
transceiver module, the other
end must use the SFP-GE-LX-SM1490-BIDI transceiver module.
Table4-4 10-GE SFP+ transceiver modules available for the SFP+ ports
10-GE SFP+
module
Central
wavelength
(nm)
Connector
Fiber
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
SFP-XG-SX-M
M850-A
850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-SX-M
M850-D
850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-SX-M
M850-E
850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-SX-M
M850-S
850 LC
Multi-mode,
50/125
2000 300 m (984.25 ft)
500 82 m (269.03 ft)
400 66 m (216.54 ft)
Multi-mode,
62.5/125
200 33 m (108.27 ft)
160 26 m (85.30 ft)
SFP-XG-LX-S
M1310-D
1310 LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
SFP-XG-LX-S
M1310-E
1310 LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
SFP-XG-LX-S
M1310-S
1310 LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
SFP-XG-LH40
-SM1550
1550 LC
Single-mode,
9/125
N/A 40 km (24.86 miles)
SFP-XG-LH40
-SM1550-D
1550 LC
Single-mode,
9/125
N/A 40 km (24.86 miles)
SFP-XG-LH80
1550 LC
Single-mode,
N/A 80 km (49.71 miles)
