H3C S5560X-HI Series User Manual

10-GE SFP+
module
Central
wavelength
(nm)
Connector
Fiber
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max
transmission
distance
-SM1550
9/125
SFP-XG-LH80
-SM1550-D
1550 LC
Single-mode,
9/125
N/A 80 km (49.71 miles)
SFP-XG-LX-S
M1270-BIDI
TX: 1270
RX: 1330
LC
Single-mode,
9/125
N/A 10 m (32.81 ft)
SFP-XG-LX-S
M1330-BIDI
TX: 1330
RX: 1270
LC
Single-mode,
9/125
N/A 10 m (32.81 ft)
SFP-XG-LH40
-SM1270-BIDI
TX: 1270
RX: 1330
LC
Single-mode,
9/125
N/A 40 km (24.86 miles)
SFP-XG-LH40
-SM1330-BIDI
TX: 1330
RX: 1270
LC
Single-mode,
9/125
N/A 40 km (24.86 miles)
SFP-XG-LH80
-SM1490-BIDI
TX: 1490
RX: 1550
LC
Single-mode,
9/125
N/A 80 km (49.71 miles)
SFP-XG-LH80
-SM1550-BIDI
TX: 1550
RX: 1490
LC
Single-mode,
9/125
N/A 80 km (49.71 miles)
IMPORTANT:
•
The SFP-XG-LX-SM1270-BIDI and SFP-XG-LX-SM1330-BIDI transceiver modules must be
used in pairs. For example, if one end uses an SFP-XG-LX-SM1270-BIDI transceiver module,
the other end must use an SFP-XG-LX-SM1330-BIDI transceiver module.
•
The SFP-XG-LH40-SM1270-BIDI and SFP-XG-LH40-SM1330-BIDI transceiver modules must
be used in pairs. For example, if one end uses an SFP-XG-LH40-SM1270-BIDI transceiver
module, the other end must use an SFP-XG-LH40-SM1330-BIDI transceiver module.
•
The SFP-XG-LH80-SM1490-BIDI and SFP-XG-LH80-SM1550-BIDI transceiver modules must
be used in pairs. For example, if one end uses an SFP-XG-LH80-SM1490-BIDI transceiver
module, the other end must use an SFP-XG-LH80-SM1550-BIDI transceiver module.
Table4-5 SFP+ copper cables available for the SFP+ ports
SFP+ copper cable Cable length
LSWM1STK 0.65 m (2.13 ft)
LSWM2STK 1.2 m (3.94 ft)
LSWM3STK 3 m (9.84 ft)
LSTM1STK 5 m (16.40 ft)
Table4-6 SFP+ fiber cables available for the SFP+ ports
SFP+ fiber cable Cable length
SFP-XG-D-AOC-7M 7 m (22.97 ft)
SFP-XG-D-AOC-10M 10 m (32.81 ft)
SFP-XG-D-AOC-20M 20 m (65.62 ft)
