7
Figure 5 Mounting and grounding positions of the S5830V2-24S
(1) Rear mounting position (2) Primary grounding point
(3) Auxiliary grounding point 1 (4) Front mounting position
Figure 6 Mounting and grounding positions of the S5820V2-52QF
(LS-5820V2-52QF)/S5820V2-52QF-U/S5820V2-52Q
(1) Auxiliary grounding point 2 (2) Rear mounting position
(3) Primary grounding point (4) Auxiliary grounding point 1
(5) Front mounting position
1 2 3 4 5
