48
Figure 53 PSR150-D1 power module
(1) Handle (2) Power receptacle
PSR450-12D
The PSR450-12D power module provides a maximum output power of 450 W.
Figure 54 PSR450-12D power module
(1) Latch (2) Status LED
(3) Handle (4) Power receptacle
High-voltage DC power modules
CAUTION:
You can install high-voltage DC power modules only on the F1090 firewall.
PSR450-12AHD
The PSR450-12AHD power module provides a maximum output power of 450 W.
