Figure 55 PSR450-12AHD power module
(1) Latch (2) Status LED
(3) Handle (4) Power receptacle
Technical specifications
Dimensions and weights
Table 14 Dimensions and weights
Firewall model
Dimensions (H × W × D), excluding rubber
feet and mounting brackets
Weight (fully
configured)
F1005/F1010 44 × 440 × 230 mm (1.73 × 17.32 × 9.06 in) 3 kg (6.61 lb)
F1020 44.2 × 440 × 435 mm (1.74 × 17.32 × 17.13 in) 6.75 kg (14.88 lb)
F1030/F1050/F1060 44.2 × 440 × 435 mm (1.74 × 17.32 × 17.13 in) 7.3 kg (16.09 lb)
F1070/F1080 44.2 × 440 × 435 mm (1.74 × 17.32 × 17.13 in) 8.5 kg (18.74 lb)
F1090 44 × 440 × 435 mm (1.73 × 17.32 × 17.13 in) 10 kg (22.05 lb)
Storage media
Table 15 Storage media specifications
Firewall model Flash Memory
F1005/F1010 256 MB NAND Flash 2GB DDR3
F1020 1 GB NAND Flash 2GB DDR3
F1030/F1050 1 GB NAND Flash 4GB DDR3
F1060/F1070 1 GB NAND Flash 8GB DDR3
F1080 1 GB NAND Flash 16GB DDR3
F1090 8 GB EMMC Flash 16GB DDR4
