H3C SecPath F1000-AI-5 Series Installation Manual

3
F1000-AI-25/F1000-AI-35/F1000-AI-55/F1000-AI
-65/F1000-AI-75
Table8-3 LED description
LED
Mark
Status
Description
System status LED SYS
Off
The firewall is not powered on or has
failed.
Flashing green
at 0.5 Hz
The firewall is operating correctly.
Flashing green
at 4 Hz
The firewall is loading software.
Power supply status LED PWR0, PWR1
Off
No power supply is present or the
power supply has failed.
Steady green
The power supply is operating
correctly.
10/100/1000BASE-T
copper port LED
10/100/1000BASE-T
Off No link is present.
Steady green A 1000 Mbps link is present.
Flashing green
The port is receiving and sending
data at 1000 Mbps.
Steady yellow A 10/100 Mbps link is present.
Flashing yellow
The port is receiving and sending
data at 10 Mbps or 100 Mbps.
1000BASE-X fiber port
LED
1000BASE-X
Off No link is present.
Steady green A 1000 Mbps link is present.
Flashing green
The port is receiving and sending
data at 1000 Mbps.
10GE fiber port LED 10GBASE-R
Off No link is present.
Steady green A 10 Gbps link is present.
Flashing green
The port is receiving and sending
data at 10 Gbps.
1000BASE-X fiber port
LED (combo interfaces)
1000BASE-X
Off No link is present.
Steady green A 1000 Mbps link is present.
Flashing green
The port is receiving and sending
data at 1000 Mbps.
10/100/1000BASE-T
copper port LED (combo
interfaces)
10/100/1000BASE-T
Off No link is present.
Steady green A 1000 Mbps link is present.
Flashing green
The port is receiving and sending
data at 1000 Mbps.
Steady yellow A 10/100 Mbps link is present.
Flashing yellow
The port is receiving and sending
data at 10 Mbps or 100 Mbps.
Interface module status
LED
Slot1, Slot2 Off
No interface module is present or the
interface module has failed.

H3C SecPath F1000-AI-5 Series Specifications

General

Brand	H3C
Model	SecPath F1000-AI-5 Series
Category	Firewall
Language	English
