Overview
This guide provides a brief introduction to processor installation on an H3C UniServer R6900 G3
server.
The preparations required before installing a processor might differ from your products.
The figures in this document are for illustration only.
Processor kit
The processor kit for an H3C UniServer R6900 G3 server includes the following components:
• Processor
• Retaining bracket
• Heatsink
A T30 Torx electric screwdriver is required for processor installation. Prepare one yourself.
Preparing for installation
WARNING!
To avoid bodily injury from hot surfaces, allow the server and its internal components to cool before
touching them.
CAUTION:
• To avoid damage to the processors or system board, only H3C-authorized personnel and
professional server engineers are allowed to install a processor.
• To avoid ESD damage, put on an ESD wrist strap before installing a processor, and make sure
the wrist strap is reliably grounded.
To prepare for processor installation:
1. Back up all server data.
2. Power down the server.
3. Disconnect the power cords.
4. (Optional.) Remove the security bezel, if any, from the server.
5. Remove the CMOD.
a. As shown in Figure 1, pre
ss the release buttons on the two sides of the CMOD towards
each other so that the locking levers project from the CMOD front panel.
