80
Figure 73 Add a target host of SNMP traps
6. Configure the settings for the target host as described in Table 42.
7. Click Apply.
Table 42 Configuration items
Item Descri
tion
Destination IP Address
Set the destination IP address or domain name.
Select the IP address type: IPv4/Domain or IPv6, and then type the
corresponding IP address or domain name in the field according to
the IP address type.
Security Name
Set the security name, which can be an SNMPv1 community name,
an SNMPv2c community name, or an SNMPv3 user name.
UDP Port
Set UDP port number.
IMPORTANT:
The default port number is 162, which is the SNMP-specified port used
for receiving traps on the NMS. Generally (such as using iMC or MIB
Browser as the NMS), you can use the default port number. To change
this parameter to another value, you need to make sure that the
configuration is the same with that on the NMS.
Security Model
Select the security model, that is, the SNMP version, which must be
the same with that running on the NMS; otherwise, the NMS cannot
receive any trap.
Security Level
Set the authentication and privacy mode for SNMP traps when the
security model is selected as v3. The available security levels are: no
authentication no privacy, authentication but no privacy, and
authentication and privacy.
