Habegger HIT-TRAC 16 E - 4 Technical Data

65
4 Technical date
Pulling force lifting / lowering
16 kN
Rope speed Standard
App. 10 m / min
Rope length
Unlimited
Stroke
Limited by motor temperature
Dimensions: width/length/height
450 mm / 700 mm / 355 mm
Drive sheave (eff.) 
250 mm
Inherent weight
57 kg
Gearbox oil
0.2 l / 80 W 90
Pulling rope
Type
Diameter
Length
Braking load
Dep. On version  8.2 or11.2 mm
HABEGGER 4 x 25 FW galvanised
8.2 mm or 11.2 mm
any length
50 kN or 88 kN
Drive motor:
Type / capacity
Electric motor
S 132-2 10 3 kW 2820 r.p.m.
Noise
Measured values determined according to EN
50 144.
The noise level of the motor-driven rope pulling
machine can exceed 85 dB (A) during operation.
Voltage - nominal current
Standard / protection type
Intermittent duty
Driving gear unit (DIN 15 020)
3 x 400 V - 6.8 A
VDE 530 / IP 44
Duty = 30%
1 C
m
DIN 15 020
Spring pressure brake
Rated braking torque
Anchor voltage
Lenze BFK 458-10-205 V
16 Nm
205 V
Control unit type
900 00022
