12
SPECIFICATIONS, continued
Operating Temperature: 0 to 50 °C (32 to 122 °F) (instrument only)
Operating Humidity Range: 0 to 90% RH noncondensing at 30 °C;
0 to 80% RH noncondensing at 40 °C;
0 to 70% RH noncondensing at 50 °C
Power Requirements: Four AA Alkaline cells or optional
battery eliminator
Battery Life: Typically 300 tests with signal average mode off;
180 tests with signal average mode on
Battery Eliminator (optional):
For 120 V eliminator: CSA and UL approved for 120 V ac ± 10%,
60 Hz, 6 V at 800 mA dc output
For 230 V eliminator: CE (VDE) approval pending for
230 V ac ± 10%, 50 Hz, 6 V at 900 mA dc output
Enclosure: High impact ABS plastic
Dimensions: 22.2 X 9.5 X 7.9 cm (8.75 X 3.75 X 3.12 in.)
Instrument Weight: 520 kg (1 lb 2.5 oz)
Shipping Weight: 3.1 kg (6 lb 8.5 oz)
