Product overview
N O T I C E
The manufacturer is not responsible for any damages due to misapplication or misuse of this product including,
without limitation, direct, incidental and consequential damages, and disclaims such damages to the full extent
permitted under applicable law. The user is solely responsible to identify critical application risks and install
appropriate mechanisms to protect processes during a possible equipment malfunction.
The AS950 controller is the controller for the AS950 AWRS, refrigerated and portable samplers.
Refer to Figure 1 on page 3. The AS950 controller can also be used as the controller for the
SD900 samplers and 900MAX samplers (AWRS, refrigerated and portable).
Refer to the sampler installation and maintenance documentation for the AS950 controller
specifications, installation, startup and maintenance information and the AS950 controller
replacement parts and accessories.
User interface and navigation
Keypad and display description
Figure 1 shows the controller keypad. Refer to Table 1 for the functions of the keys on the keypad.
Refer to Table 2 for the indicator light description.
Push the power key to set the controller to on or off. To save power, the display switches off after
5 minutes of no keypad use. Push a key to set the display back to on.
Figure 1 Controller keypad and display
1 Power key 5 Indicator light 9 CALIBRATION key
2 Arrow keys 6 STATUS key 10 MANUAL OPERATION key
3 Soft keys 7 MENU key 11 RUN/HALT key
4 Display 8 STOP key
English 3
