Section 5 Repairs
D A N G E R
Electrocution hazard. Remove power from the instrument before this procedure is started.
W A R N I N G
Chemical exposure hazard. Obey laboratory safety procedures and wear all of the
personal protective equipment appropriate to the chemicals that are handled. Refer to the
current safety data sheets (MSDS/SDS) for safety protocols.
5.1 Open the instrument
Items to collect:
• Coin
• TORX 10 torque screw driver
• Krytox oil (item no. 16004801)
Step Description Picture
1 To open the battery compartment, use a coin.
2 Remove the batteries.
35
