Category Code Value Short description Detailed description
error 116 Error: ADC [DR300]ADC_CHANNEL_LED_VOLTAGE=1
ADC_CHANNEL_LED_MON=2
ADC_CHANNEL_BATTERY_VOLTAGE =3
ADC_CHANNEL_HARDWARE_ID=4
ADC_CHANNEL_MODULE_ID_CODE =15
ADC_CHANNEL_STM32_TEMPERA TURE=17
[none] Type: ADC=23, Timeout=231,
Invalid=232
[none] Channel
[none] Sampling time
standard
message
117 Instrument information
[none] Mainboard serial
[none] Bootloader version
[none] Hardware version
[none] Module ID
[none] BLE module version (if equipped)
[%] HWC LED adjust
[none] HWC LED adjust timestamp
[none] BLE module MAC address (if
equipped)
error 118 Parameter load error
6.2 Get the data logger
1. Install the service cable VAA10036.99.G00 in the DR300. Refer to Insert the service
cable on page 19.
2. Start the VAP235 software.
3. Connect the service cable VAA10036.99.G00 to an USB port.
4. Push on the DR300.
5. Push Connect. The display of the DR300 shows serial.
6. Push Get data log.
7. Define the path to store the data logger. Refer to Figure 13.
8. Find the csv file in the path which is defined. E.g.
DL_LPG445.99.00000_SN18060A000047_180926_1544.csv. Refer to Figure 14.
Troubleshooting
61
