Installation
The Flo-Dar sensor dimensions are shown in Figure 5 and Figure 6.
Figure 5 Flo-Dar sensor dimensions
1 Optional extended depth sensor 3 Minimum clearance for cable
2 Minimum clearance for cable with extended depth sensor
