Table of contents
Specifications on page 3 Calibration on page 15
General information on page 4 Measurement process on page 17
Installation on page 5 Analysis on page 18
User interface on page 8 Maintenance on page 19
Configuration on page 9 Troubleshooting on page 23
Additional information
Additional information is available on the manufacturer's website.
Specifications
Specifications are subject to change without notice
Specification Details
Measurement range O
2
1 ppb - 12 ppm
CO
2
0.75 - 5 V/V or 1.5 - 10 g/kg
Repeatability r
95
Total Package Oxygen ± 5 μg/L ± 10% whichever is the greater
CO
2
on equilibrated packages at T =
10 to 25°C (50 to 77°F)
± 0.05 V/V or 0.10 g/kg ± 2% whichever is
the greater
O
2
± 2 ppb ± 10% whichever is the greater
Typical analysis time About 4 minutes
Display units O
2
concentration ppb or ppm
CO
2
concentration V/V, g/kg, g/L or %W
Pressure bar, mbar, psia
Temperature °C, °F or K
Operating limits Package temperature -2 to 30°C (28 to 86°F)
Package pressure 1.4 to 6.8 bar absolute (20 - 99 psia)
Ambient temperature 0 to 40°C (32 to 104°F)
Relative humidity Up to 80%
Package setup Maximum package height 340 mm (13.39 ins)
Minimum package height 90 mm (3.54 ins)
Minimum volume 150 ml
Material Glass, PET or aluminum
Dimensions (L x W x H) 537 x 540 x 942 mm (21.1 x 21.3 x 37.1 ins)
Weight 55 kg (121 lbs)
Enclosure protection IP20
Power requirements 100-240 VAC ±10% @ 50-60 Hz
Power consumption Max. 250 VA
Purge gas CO
2
with purity > 99.9% at 6 to 7 bar absolute (87 to 102 psia)
English 3
