Hach sc100 User Manual

12
Installation
Figure 5 Panel Mount Cut-out Dimensions
Figure 6 Conduit Hole Dimensions
133 mm (5.25 )inches
144 mm (5.67 )inches
ref only()
135 mm
(5.31 )inches
144 mm
(5.67 )
()
inches
ref only
67.4 mm
(2.65 )inches
72 mm
(2.835 )inches
ref only()
66.67 mm (2.625 )inches
75 mm (2.955 )inches
(ref only)
6.35 mm (0.25 inch)
15.24 mm (0.60 inch)
28.57 mm (1.125 inches)
75.07 mm (2.955 inches)
127 mm
(5.00 inches)
150 mm
(5.91 inches)
(ref only)
99.31 mm
(3.91 inches)
50.8 mm
(2.00 inches)
28.57 mm (1.125 inches)
68.96 mm (2.715 inches)
25.4 mm (1.00 inch)
25.4 mm (1.00 inch)
144 mm (5.67 inches)
