39
Operation
NETWORK SETUP (this menu appears only if a network card is installed in the controller)
SET MODE
Auto or Manual
MODBUS ADDRESS
Highlight sc100 Analyzer, or either connected sensor then press ENTER. Choose a number between 1 and 247 as the
address (each source must have a different address) then press ENTER.
BAUD RATE
Select a baud rate of 9600, 19200, 38.4K, 57.6K, or 115.2K. Default: 19200
STOP BITS
Select 1 or 2 stop bits. Default: 1
MODBUS MODE
Select RTU or ASCI. Default: RTU
DATA ORDER
Select Normal or Swapped. Default: Swapped
DISPLAY SETUP
ADJUST CONTRAST
Use the UP and DOWN keys to increase or decrease the contrast, see section 4.3.1 on page 31.
LANGUAGE
The default is English. Choose Spanish, German, or French to allow all menus to appear in the selected language.
SET DATE/TIME
Select the date format and to set the date and time (24-hour (military) format), see section 4.3.3 on page 32.
SECURITY SETUP (Enter a 6-digit passcode)
SET PASSCODE
DIISABLE
Disables system security. See section 4.4 on page 33.
ENABLE
Enables system security. See section 4.4 on page 33.
LOG SETUP
DATALOG SETUP
Setup datalogging of displayed sensor measurements
CALCULATION
SET VARIABLE X
Select the sensor corresponding to the variable set as “X”.
SET VARIABLE Y
Select the sensor corresponding to the variable set as “Y”.
SET PARAMETER
Select the parameter to be associated with the variable.
SET FORMULA
Select the formula of the calculation to be performed on “X” and “Y”.
4.9 System Setup Menu (continued)
