Table of contents
Specifications on page 3 Operation on page 20
General information on page 4 Maintenance on page 21
Installation on page 8 Troubleshooting on page 21
User interface on page 19 Replacement parts and accessories on page 22
Startup on page 20
Specifications
Specifications are subject to change without notice.
Specification Details
Dimensions (W x H x D) ½ DIN—144 x 144 x 192 mm (5.7 x 5.7 x 7.6 in.)
Weight 1.7 kg (3.7 lb) (Controller weight without optional modules)
Enclosure NEMA 4X/IP66 metal enclosure with a corrosion-resistant finish
Operating temperature –20 to 60 °C (–4 to 140 °F); Cellular version: –20 to 55 °C (–4 to 131 °F)
Storage temperature –20 to 70 °C (–4 to 158 °F)
Relative humidity 0 to 95%, non-condensing
Altitude 2000 m (6562 ft) maximum
Installation category II
Pollution degree 2
Protection class I, connected to protective earth
Power requirements 100–240 VAC ±10%, 50/60 Hz; 0.5 A (7 Watt sensor load)
Measurement Two device digital SC connectors
Relays high voltage Two relays (SPDT); Maximum switching voltage: 250 VAC; Maximum switching
current: 5 A (resistive only load); Maximum switching power: 1250 VA, 125 W
(resistive only load); Wire gauge: 0.75 to 2.5 mm
2
(18 to 12 AWG)
Outputs (optional) Five 4–20 mA analog outputs on each analog output module
1
Analog input (0–20 mA or 4–20 mA) on each analog input module
Digital communication Profibus DPV1 card
1
(optional), Modbus TCP/IP
Network connection
2
LAN version: Two Ethernet connectors (10/100 Mbps), switch function, M12 female D-
coding connector; Cellular version (optional): SIM card (3G/4G); WiFi version
(optional)
USB port Used for data download and software upload. The controller records approximately
20,000 data points for each connected sensor.
Compliance information CE. ETL certified to UL and CSA safety standards (with all sensor types).
Warranty 1 year (EU: 2 years)
1
Refer to the module documentation for additional information.
Note: Connect only one module to one of the available slots.
2
The type of connection is dependent on controller configuration.
English 3
