Product components
Make sure that all components have been received. Refer to Figure 2. If any items are missing or
damaged, contact the manufacturer or a sales representative immediately.
Figure 2 Product components
1 SC4200c controller 8 Flat washer, ¼-inch ID (4x)
2 Mounting hardware 9 Lock washer, ¼-inch ID (4x)
3 Sealing gasket for panel mount, Neoprene 10 Keps hexnut, M5 x 0.8 (4x)
4 Vibration isolation gasket for pipe mount 11 Pan head screws, M5 x 0.8 x 15 mm (4x)
5 Vibration isolation washer for pipe mount (4x) 12 Pan head screws, M5 x 0.8 x 100 mm (4x)
7
6 Bracket for wall and pipe mounting
6
13 Screwdriver, 2-mm wide blade
7 Mounting foot (mounting bracket inserts) (2x)
Installation
D A N G E R
Multiple hazards. Only qualified personnel must conduct the tasks described in this section of the
document.
6
A bracket for panel mounting is available as an optional accessory. Refer to Replacement parts
and accessories on page 30.
7
Used for variable diameter pipe mount installations.
English 9
