Machine Symbol
Chart
(as per IEC 601–1:88)
Ty p e B F
Class 1 equipment with isolated (floating) applied part
providing adequate protection against electrical shock,
particularly regarding allowable leakage currents and
reliability of the protective earth connection.
Alternating Current
IPX1 Protection against Dripping Water
Power Off
Power On
Protective Earth
Attention (consult accompanying documents)
Fuse Symbol
!
