Hafco EB-270DSA - Page 23

- 22 -
PART LIST
Part
No.
Description Size No. Q’ty
Part
No.
Description Size No. Q’ty
92-2
Changeable Plate 1
151
Reduction Unit 1
92-3
Hex. Socket Cap Screw M8x16 4
152
Key 8x8x30 1
94
Bar-Stop-Rod 1
152-1
Vent Screw 1
95
Bar-Stop 1
153
Hex. Cap Bolt M8x30 4
96
Handle M10x35 1
153-1
Spring Washer M8 4
97
Scale 1
154
Motor 1
98
Rivet 3
154-1
Junction Box 1
102
No-Burr Jaw 1
155
Key 8x7x35 1
103
Hex. Socket Cap Screw M6x20 2
156
Anchoring Dowel 1
104
Counter Vise Jaw 1
157
Hex. Socket Cap Screw M8x25 4
105
Hex. Socket Cap Screw M6x15 2
157-1
Spring Washer M8 4
106
Vise Jaw 1
158
Hollow Pin
6x20
2
107
Flat Head Machine Screw M6x15 2
159
Coupling Fork 1
108
Vise 1
160
Pin on Fork 1
109
Dovetail Plate 1
161
C-Ring S-20 2
110
Nut M5 3
162
Nut 1
111
Set Screw M5x25 3
163
Rod Supporting Block 1
112
Vise Screw for Hydraulic Drive 1
164
Hex. Socket Cap Screw M10x30 1
112-1
Hex. Socket Cap Screw M8x16 1
164-1
Spring Washer M10 2
112-2
Washer M8 1
165
Nut M10 1
113
Key 5x5x15 1
166
Hex. Socket Cap Screw M10x40 1
114
Hydraulic Cylinder (Vise) 1
167
Adjustable Stop 1
115
Spring Washer M8 4
168
Handle M8x25 1
116
Hex. Socket Cap Screw M8x25 4
169
Stop Bar 1
117
Hand Wheel 1
170
Adjustable Stop 1
117-1
Spring Washer M6 1
170-1
Set Screw M8x10 1
117-2
Hex. Socket Cap Screw M6x25 1
171
Hydraulic Cylinder (Arm) 1
117-3
Bushing 1
172
Bushing 2
118
Set Screw M8x10 1
173
Hex. Socket Cap Screw M12x20 2
120
Vise Seat 1
174A
Limit Switch Plate 1
122
Vise Setting Plate 1
175
Spring Washer M8 4
123
Hex. Socket Cap Screw M10x35 2
176
Nut M8 4
124
Washer 3/4”x37x3 1
177
Spring Washer M6 2
125
Lock Lever Device 1
178
Hex. Socket Cap Screw M6x12 2
127
Handle 1
179
Limit Switch 2
128
Setting Plate 1
180
Hex. Socket Cap Screw M6x25 4
129
Bushing 1
181
Spring Holder 1
130
Hex. Socket Cap Screw M8x20 2
182
Nut M8 2
130-1
Spring Washer M8 2
183
Hex. Cap Bolt M12x30 2
131
Electric Box Holder 1
183-1
Spring Washer M12 2
132
Spring Washer M8 4
184
Cylinder Guard 1
133
Hex. Socket Cap Screw M8x20 4
185
Hex. Socket Cap Screw M6x60 2
135
Hex. Socket Cap Screw M10x25 2
185-1
Hex. Socket Cap Screw M5x8 1
136
Spring Washer M10 2
186
Hex. Socket Cap Screw M10x35 4
138
Hex. Socket Cap Screw M6x25 2
186-1
Spring Washer M10 4
138-1
Washer M6 2
187
Cylinder Coupling 1
139
Nut M6 2
188
Spring Hook 3/8” 1
140-5
Magnetic Switch 2
189
Spring 1
140-6
Overload Relay 1.2A 1
190
Setting Bushing 1
140-8
Hex. Cap Bolt M6x15 2
191
Washer M8 1
140-11
Overload Relay 1
192
Hex. Socket Cap Screw M8x35 1
142
Hex. Socket Cap Screw M5x8 10
193A
Saw Arm 1
143
Nut M5 4
194
Hex. Socket Cap Screw M10x30 4
146
Round Head Screw M5x10 4
194-1
Spring Washer M10 4
147-2
Main Connect Switch 1
195
Limit Switch 1
147-5
Speed Selector 1
195-1
Switch Pin 1
1000615
23
Instruction Manual for EB-270DSA (B066)
31/03/2016
