12 MACHINE COMPONETS
12.1 PART LIST
Part
No.
Description Size No. Q’ty
Part
No.
Description Size No. Q’ty
1
Base (Bottom Plate) 1
47
Roller 1
2
Base (Left Part) 1
48
Ball Bearing 6004ZZ 2
2-1
Nut M8 2
48-1
C-Ring S-20 2
3
Base (Right Part) 1
49
Roller Shaft 1
4
Base (Front Part) 1
50
Hex. Socket Cap Screw M10x20 2
4-1
Hex. Cap Bolt M8x16 2
50-1
Spring Washer M10 2
4-2
Washer M8 4
51
Pedal Plate 1
5
Hex. Cap Bolt M12x40 2
53
Pedal Switch 1
6
Nut M12 2
53-1
Micro Switch 1
8
Hex. Cap Bolt M8x16 6
54
Round Head Screw M4x10 4
8-1
Washer M8 6
55
Hex. Socket Cap Screw M6x8 1
9
Plate 1
56A
Emergency Switch Box 1
10
Hex. Socket Cap Screw M5x8 4
56-1
Pipe 1
11
Coolant Tank 1
57-1
Flat Head Cross Screw 4
12
Hex. Cap Bolt M8x16 2
58
Hex. Socket Cap Screw M5x8 4
13
Coolant Gauge 1
58-1
Nut M4 4
13-1
Nut M10 2
59A
Emergency Switch 1
13-2
Washer M10 2
60A
Handle 1
14
Hex. Cap Bolt 3/16” 2
60-1
Hex. Socket Cap Screw M8x20 2
15
Tank Cover 1
60-2
Nut M8 2
16
Filter 1
61
Handle 1
17
Pump 1
61-1
Nut M12 1
18
Hex. Socket Cap Screw M6x25 2
63
Locking Lever 1
18-1
Washer M6 2
63-1
Set Screw M8x10 1
22
Hose Clamp 13mm 1
64
Hex. Socket Cap Screw M10x35 1
23
Hose 5/16”x235cm 1
64-1
Spring Washer M10 1
23-1
Hose 1”x45cm 1
65
Shaft Nut 1
24
Coolant and Chip Tray 1
65-1
Oil Seal 1
24-1
Block Plate 1
65-3
Disk 1
25
Mounting Bracket 2
65-4
Spring Washer M8 4
26
Spring Washer M10 4
65-5
Hex. Socket Cap Screw M8x30 4
27
Hex. Socket Cap Screw M10x20 4
66A
Shaft 1
28
Washer M10 4
68
Swivel Arm 1
29
Hex. Cap Bolt M10x20 4
68-1
Hex. Cap Bolt M10x35 1
29-1
Washer M10 4
69
Scale 1
30
Hex. Cap Bolt M12x40 2
70
Rivet 2.3x4 2
31
Nut M12 2
71
Pin 1
32
Scale 1
72
Hollow Pin
2.5x16
1
33
Round Head Screw M5x10 2
73
Spring 1
34
Nut 1
74
Bushing 1
34-1
Washer M34 1
75
Bracket 1
35
Switch 1
76
Spring Washer M8 2
36
Emergency Switch 1
77
Hex. Socket Cap Screw M8x25 2
37
Grommet 2
78
Knob 1
38
Grommet 1
79
Jam Nut M35 1
39
Track 1
80
Star Washer M35 1
40
Hex. Socket Cap Screw M8x35 2
81
Anti-Dust Cover M35 2
40-1
Nut M8 2
82
Ball Bearing 32007 2
40-2
Spring Washer M8 2
83
Shaft 1
41
Set Screw M6x12 4
84
Hex. Cap Bolt M10x45 1
42
Washer 1
85
Nut M10 2
43
Handle M8x25 1
86A
Pointer 1
44
Roller Stand 1
87
Hex. Socket Cap Screw M5x8 1
45
Hex. Cap Bolt M12x25 2
88-2
Set Screw M8x10 1
46
Spring Washer M12 2
92B
Table 1
46-1
Washer M12 2
92-1
Set Screw M6x12 1
1000615
22
