SCHEMATIC DIAGRAM
NOTES: Unless specified otherwise
1. All resistors in ohms
2. All capacitors in microfarads
3. Component Designators:
1-99: Left Channel
101-199: Right Channel
201-299: Common Parts
301-399: Chassis/Power Supply
4. Left Channel Only Shown
5. Stereo/Mono Switch Shown in Stereo
6. Balanced/Unbalanced Switch Shown in Balanced Position
7. Chassis/Float Ground Switch Shown in Float Position
