hager 4500 Series User Manual

4500 Series Surface Vertical Rod Exit Device
Installation Instructions
Grade 1
I-ED00792
REV 3 Page 11 of 11
15. INSTALL AUXILIARY FIRE LATCH (for LBR devices only)
A. The Auxiliary Fire Latch must be installed to maintain fire listing.
B. Refer to Auxiliary Fire Latch Installation Instructions (I-ED00863) for details.
1 3/4"
HOLE
DEPTH
44
C
L
6"
FROM
BOTTOM
OF DOOR
152
1"
25
1/16"
2
3 7/16"
HOLE DEPTH
87
1"
25
1 25/32"
45
5/8"
16
5/8"
16
7/8"
22
R 1/8"
3
1/4"
6
1/4"
6
#29 DRILL
(.136")
4 PLACES
C
L
DOOR
C
L
DOOR
C
L
STRIKE HOLE PLUG
DOOR LEAF
AUXILIARY FIRE LATCH
DOOR LEAF
26490169

hager 4500 Series Specifications

General

Brand	hager
Model	4500 Series
Category	Door Opening System
Language	English
