4500 Series Surface Vertical Rod Exit Device
Installation Instructions
Grade 1
I-ED00792
REV 3 Page 2 of 11
EXIT DEVICE PARTS AND SUB-ASSEMBLIES
DEVICE BODY
DOGGING DEVICE
(ONLY ON PANIC HARDWARE)
PUSH BAR
END CAP
BRACKET
END CAP
CHASSIS COVER
ROD GUIDE
BOTTOM LATCH
COVER
MOUNTING
BRACKET
BOTTOM LATCH
ASSEMBLY
BOTTOM STRIKE
(FIRE RATED)
BOTTOM STRIKE
(PANIC RATED)
BOTTOM STRIKE ANCHOR
SEX BOLTS
CHASSIS
BOTTOM ROD
ROD CONNECTOR
TOP LATCH
COVER
TOP LATCH
ASSEMBLY
MOUNTING BRACKET
TOP STRIKE
(PANIC RATED)
TOP STRIKE
(FIRE RATED)
HEX
WRENCH
26490169
