Haier H-MRV Series - Indoor Unit Specifications

>a__WcU[S^ <[c >a`V[e[a`Wc
2.2 Specifications for indoor units
AB092FCBHA AB142FCBHA
Cooling capacity
Bt
u
／h
9000 14000
Heating capacity
Bt
u
／h
12000 16000
Cooling capacity W 2600 4100
Heating capacity W 3500 4700
Dehumidifying capacity
1
0
‐³×m³/h
1.6 2.1
Power source
N，V，Hz
Power consumption W 15 15
Running current A 0.07 0.07
Starting current A 0.2 0.2
Refrigerant R407C R407C
Noise level(H/M/L) dB(A) 42.6/35.0/31.7 42.6/35.0/31.7
Type × Number centrifugal fan×1 centrifugal fan×1
Air-flow(H-M-L) m³/h 705/624/511 705/624/511
Fan motor output W 15 15
starting mothod Relay control Relay control
Heat exchanger
Refrigerant control method
External mm×mm×mm 570×570×276 570×570×276
Shipping mm×mm×mm 715×715×361 715×715×361
External mm×mm×mm 630×630×80 630×630×80
Shipping mm×mm×mm 685×685×150 685×685×150
Net kg / kg 26/4.2 26/4.2
Shipping kg / kg 28/6.3 28/6.3
Liquid mm (inch) 6.35 (1/4") 6.35 (1/4")
Gas mm (inch) 9.52 (3/8") 12.7 (1/2")
Connection method flared flared
Suited area m2 12~23 17~27
Controller type
AB182FCBHA AC142FCBHA
Cooling capacity
Bt
u
／h
18000 14000
Heating capacity
Bt
u
／h
21000 16000
Cooling capacity W 5300 4100
Heating capacity W 6200 4700
Dehumidifying capacity
1
0
‐³×m³/h
2.1 2.1
Power source
N，V，Hz
Power consumption W 20 70
Running current A 0.09 0.3
Starting current A 0.3 0.9
Refrigerant R407C R407C
Noise level(H/M/L) dB(A) 42.6/35.0/31.7 48/44/38
Type × Number centrifugal fan×1 centrifugal fan×1
Air-flow(H-M-L) m³/h 1050/910/850 920/815/704
Fan motor output W 20 70
starting mothod Relay control Relay control
Heat exchanger
Refrigerant control method
External mm×mm×mm 570×570×276 990×655×199
Shipping mm×mm×mm 715×715×361 1160×760×310
External mm×mm×mm 630×630×80 /
Shipping mm×mm×mm 685×685×150 /
Net kg / kg 26/4.2 30
Shipping kg / kg 28/6.3 39
Liquid mm (inch) 9.52(3/8") 9.52(3/8")
Gas mm (inch) 15.88(5/8") 15.88(5/8")
Connection method flared flared
Suited area m2 22~33 16~23
Controller type
wired controller or remote
controller
remote controller
Item Model
Fan
Combination of wave cranny radiation fin and copper pipe
Electronic expansion valve
1PH 220V-230V 50HZ
Dimension（L×W×H）
Panel dimension (L×W×H)
Weight(unit/panel)
Piping
wired controller or remote controller
Item Model
Fan
Combination of wave cranny radiation fin and copper pipe
1PH 220V-230V 50HZ
Piping
Electronic expansion valve
Dimension（L×W×H）
Panel dimension (L×W×H)
Weight(unit/panel)
-11-
