38 driving chip
TD62083AP/ULN2083 IC4 1
39 NAND gate
HD14011BP/TC4011BP IC2 1
40 power supply monitor
PST600D IC3,IC10 2
41 constant voltage board
MC7805 IC5 1
42
973 radiator
6F25 single hole, two feet (with
screw) matched with IC5 1
43
2-pin socket TJC8-2A straight pin CJ1,CJ2 2
44
10-pin socket B10B-XH-A(white) CN18 1
45
2-pin socket B2B-XH-A(white) CN9 1
46
2-pin socket B2B-XH-A(black) CN4 1
47
2-pin socket B2B-XH-A(red) CN1 1
48
2-pin socket B2P2-VH(white) CN15 1
49
2-pin socket B2P2-VH(red) CN14 1
50
3-pin socket B3B-XH-A(white) CN8, CN17 2
51
3-pin socket B3B-XH-A(black) CN6 1
52
3-pin socket B3B-XH-A(red) CN12(no used) 1
53
3-pin socket B3B-XH-A(yellow) CN7 1
54
3-pin socket B3B-XH-A(blue) CN13(no used) 1
55
3-pin socket B3B-XH-A(green) CN5 1
56
4-pin socket B4P-SHF-1AA(red) CN10 1
57
4-pin socket B4P-SHF-1AA(blue) CN11 1
58
5-pin socket B5B-XH-A(white) CN2 1
59
5-pin socket B5B-XH-A(red) CN3 1
60
6-pin socket B6B-XH-A(white) CN21, CN22 2
61
6-pin socket B6P-SHF-1AA CN23(no used) 1
62
8-pin socket B8B-XH-A(white) CN16 1
63
PCB 1-8MB.PCB -------- 1
64
socket EEPROM BR93LC56 -------- 1
-133-
