3.4.1 Function Description: Display the signal.
3.4.2 Connector definition
CN1 (Header):S14B-PH-SM4-TB (D)(LF)(JST) or equivalent.
Pin No. Symbol Description
1
2
3
VBL
+5.0V Power input
4
5
6
13
14
25
26
GND
Ground
7-12
15
LVDS
LVDS EVEN Signal
Pin number Signal name Description
1-3 LVDSVDD Power for panel
4-6 GND Ground
7 A0N LVDS EVEN 0 - Signal
8 A0P LVDS EVEN 0 + Signal
9 A1N LVDS EVEN 1 - Signal
10 A1P LVDS EVEN 1 + Signal
11 A2N LVDS EVEN 2 - Signal
12 A2P LVDS EVEN 2 + Signal
13,14 GND Ground
15 CK1N LVDS EVEN Clock - Signal
16 CK1P LVDS EVEN Clock + Signal
17 A3N LVDS EVEN 3 - Signal
18 A3P LVDS EVEN 3 + Signal
19 A4N LVDS ODD 0 - Signal
20 A4P LVDS ODD 0 + Signal
21 A5N LVDS ODD 1 - Signal
22 A5P LVDS ODD 1 + Signal
23 A6N LVDS ODD 2 - Signal
24 A6P LVDS ODD 2 + Signal
25,26 GND Ground
27 CK2N LVDS ODD Clock - Signal
28 CK2P LVDS ODD Clock + Signal
29 A7N LVDS ODD 3 - Signal
30 A7P LVDS ODD 3+ Signal
To Next Page
