3.3.1Function Description:
Supply power for Main board and Panel.
3.3.2Connectordefinition
INPUT CONNECTOR (CN6)
3.4.LCD PANNEL.
CN10 Signal name
1 N
2 GND
3 GND
4 DIM
5 EN
6 +12V
7 +12V
CPT（CLAA220WA01 V2）
