3
1. Specification
Model HLC22R
Screen size 21.6inch
Aspect ratio 16:10
Resolution 1680*1050
Response Time（ms)
5
Angel of view H:170/V:160
Color display 16.7M
NO.of preset channels 181
OSD language English/Spanish/French
Color system Notes 1
Audio system Notes 2
Audio output
power(Built-in)(W)
2×1.5W
Audio output
power(outer)(W)
No
Total power input（W） ＜＝60W
Voltage range（V）
AC120V
Power frequency（Hz）
60Hz
Time of sleep
timer(MINS)
240Min
Net weight(KG) 6.2
Gross weight(KG) 7.1
Net dimension(MM)
524*180*434
Packaged
dimension(MM)
582*216*500
Notes:
1.NTSC:
Standards Developed by National TV Standards Committee
2. M standard: each channel bandwidth is 6 MHz and the frequency of audio is 4.5 MHz higher than the
frequency of video.
