Haier HRF-628AF6 - Page 27

Parameter of the sensors
1
T(℃)
The
resistance(
±
5%
K
)
T(℃)
The
resistance
(±
5%
K)
T(℃)
The
resistance
(±
5%
K)
R type
F type
R type
F type
R type
F type
-30 33.070 33.84 1 6.038 6.162 32 1.452 1.478
-29 31.160 31.88 2 5.743 5.861 33 1.392 1.418
-28 29.370 30.04 3 5.464 6.576 34 1.336 1.360
-27 27.690 28.32 4 5.201 5.306 35 1.281 1.304
-26 26.120 26.70 5 4.950 5.051 36 1.230 1.252
-25 24.640 25.19 6 4.714 4.810 37 1.181 1.201
-24 23.250 23.77 7 4.491 4.581 38 1.134 1.153
-23 21.950 22.43 8 4.279 4.365 39 1.089 1.108
-22 20.730 21.18 9 4.078 4.160 40 1.046 1.064
-21 19.580 20.00 10 3.887 3.965 41 1.005 1.022
-20 18.500 18.90 11 3.707 3.781 42 0.966 0.982
-19 17.490 17.86 12 3.536 3.606 43 0.928 0.944
-18 16.540 16.89 13 3.373 3.440 44 0.892 0.908
-17 15.640 15.97 14 3.219 3.283 45 0.858 0.873
-16 14.800 15.11 15 3.073 3.134 46 0.826 0.839
-15 14.000 14.30 16 2.935 2.922 47 0.794 0.808
-14 13.250 13.53 17 2.803 2.858 48 0.764 0.777
-13 12.550 12.81 18 2.678 2.730 49 0.736 0.748
-12 11.890 12.14 19 2.559 2.609 50 0.708 0.720
-11 11.270 11.51 20 2.446 2.493 70 0.346 0.351
-10 10.680
10.906
21 2.339 2.384
-9 10.120
10.341
22 2.237 2.280
-8 9.600
9.8067
23 2.140 2.180
-7 9.108
9.3031
24 2.047 2.086
-6 8.643 8.821 25 1.960 1.977
-5 8.204 8.373 26 1.876 1.911
-4 7.790 7.95 27 1.796 1.830
-3 7.398 7.551 28 1.721 1.753
-2 7.029 7.173 29 1.649 1.679
-1 6.680 6.817 30 1.580 1.609
0 6.350 6.48 31 1.514 1.542
