HSU-18HEA03/R2(DB)-I Removal Procedure
Domestic Air Conditioner
88
9.1.5 Removal of Vertical Blades and Display Board
Step Procedure Points
1
Pull out the
Vertical Blades.
2
/RRVHQWKH¿[LQJ
screws,and remove
the display board.
3
Loosen the screw of
the drip proof plate.
Lift and remove
the electrical box.
