Removal Procedure
9.1.7 Removal of Fan Motor and Heat Exchanger
stnioP
erudecorPpetS
1. Remove the
right side plate.
1 Loosen the
2 screws.
2 Remove the
3 Lift up the
evaporator
Be careful not to
evaporator.
3. Remove the fan.
1 Loosen the
2 screws.
12/ VHJ(DB)
80
You can detach the indoor
unit without removing the
assembly of the outlet grille.
Caution
If gas leaks, repair the spot of
leaking, then collect all
refrigerant from the unit. After
conducting vacuum drying,
recharge proper amount of
refrigerant.
Caution
Do not contaminate any gas
(including air) other than the
specified refrigerant (R410A),
into refrigerant cycle.
(Contaminating of air or other
gas causes abnormal high
pressure in refrigerating
cycle, and this results in pipe
breakage or personal
injuries.)
Pay attention so that the
residual water in the drain
will not make the floor wet.
In case that a drain hose is
buried inside a wall, remove
it after the drain hose in the
wall is pulled out.
Use two wrenches to
disconnect pipes.
When disconnecting pipes,
cover every nozzle with caps
so as not to let dust and
moisture in.
Caution
