Back light connectors (CN23)
Pin number
Signal name
Description
ADJ
PBON
GND
5VS
Back light adjust
Back light ON/OFF
GND
5VS
Speaker connector (CN26)
1
2
3
Pin number
Signal name
Description
L+
L+
L-
4
R+
Left of audio
Right of audio
Power of audio anplifier connector (CN27)
1
2
3
Pin number
Signal name
Description
GND GND
24V 24V
24V 24V
4
GND GND
Left of audio
Right of audio
Key connector (CN25)
1
2
3
Pin number
Signal name
Description
GND GND
KEY1 KEY1
KEY0 KEY0
Remote connector (CN24)
1
2
3
Pin number
Signal name
Description
4
5
5V
5V
IRIN
IR IN
LEDR
LED-RED
LEDB
LED-BLUE
GND GND
