4-2.Mainboard
4-2-1. Function Description:
Process signal which incept from exterior equipment then translate into signal that panel can display.
4-2-2-1.Mainboard of L26F6 L32F6
4-2-2.Connector definition
CN24
4-2-2-2.Connector definition
CN25
CN27
CN26
CN23
CN18
CN21
CN22
Power connectors (CN18)
Pin number
Signal name
Description
5
6
7
ON/OFF
PW-ON/OFF
GND
GND
5VS
5V-Stand
GND
GND
GND
GND
12VA
12V-Mainboard
12VA
12V-Mainboard
1
2
3
4
Service Manual
Model No.:
/)
23
