4-3. Power Supply Board
4-3-1. Function description:
To supply power for Mainboard, Panel.
4-3-2. Connector defi nition:
4-3-2-1.L26F6
CN2
CN3 CN5
CN1
1
2
Pin number
Signal name
L
N
CN1
CN5
Pin number
Signal name
1
2
3
4
GND
GND
+24VD
+24VD
CN3
Pin number
Signal name
1-5
6-10
GND
+24V
CN2
Pin number
Signal name
Pin number
Signal name
1
2
3
4
5
6
PS_ON
+5V
GND
GND
7
GND
+12V
+12V
Service Manual
Model No.:
/)
26
